UNI 803 ZDA 58 50 01
Specifications:
- Slim width 23.6 mm design, Zero cross over SSR
- Input : 4-32VDC / 4-16mA, RED LED Indication
- Output : 24-580VAC(47-63 Hz), 50 Amp
- PIV : 1400, I²T : 3000A²S for 9.6mS
- Body insulation : 4kV for 1min
- I/P. to O/P. insulation : 8kV for 1min
- Inbuilt surge voltage protection of 2700Vrms
- Short Circuit Protection by “B” Curve DP MCB
- Resistive load Max 15 A SC protect by 16 A DP MCB
- Short Circuit Current Rating : 10kA for <3mS
Product Details:
- Voltage Type:- DC TO AC
- Current:- 50 AMP
- Type:- Solid State Relay
- Heat Sink:- Not Included
- Color:- Black
- Materiel:- Plastic
